Product Details:
|
| Rated Input Voltage: | 220V±15% | Rated Duty Cycle @40°C: | 80% |
|---|---|---|---|
| Max. Load Power Capacity: | 40kva | Rated Output Voltage: | 85 V |
| Rated Output Current: | 500 | Welding Current/Voltage Range: | 30-400A |
| Condition: | New | Motor Type: | DC MOTOR |
| Dimensions: | 930*620*640MM | Use: | PIPELINE WELDING |
| Weight (KG): | 155 KG | Warranty: | 1 Year |
| Key Selling Points: | WELDER + GENERATOR | Applicable Industries: | Manufacturing Plant, Construction Works , Energy & Mining |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Feature: | Multifunction | Welding Machine Type: | ENGINE DRIVEN WELDER |
| Function: | Welder + Generator | Port: | TIANJIN |
|
Brush
|
-
|
No brush
|
|
Rated Output
|
KW
|
9.6
|
|
Rated Current
|
DCA
|
300
|
|
Rated Voltage
|
DCV
|
32
|
|
Open-circuit Voltage
|
DCV
|
75
|
|
Duty Cycle
|
%
|
50
|
|
Rated speed
|
rpm
|
3600
|
|
Type
|
-
|
Rectified DC output type
|
|
Applicable Electrode
|
mm
|
2.0-6.0
|
|
Rated Output
|
KW
|
3.0
|
|
Rated Voltage
|
DCV
|
220V-120V
|
|
Rate
|
-
|
100%
|
|
Driven
|
-
|
Direct coupling
|
|
Model
|
-
|
Kohler CH640/Honda GX630
|
|
Type
|
-
|
4-stroke, Gasoline
|
|
Cylinder arrangement
|
-
|
Twin cylinder
|
|
Total displacement
|
cc
|
624/688
|
|
Max Output
|
KW
|
14.7
|
|
Speed
|
rpm
|
3600
|
|
Cooling System
|
-
|
Air cool
|
|
Start System
|
-
|
Electric start
|
|
Fuel Tank Capacity
|
L
|
6.5 or 17
|
|
Battery Capacity
|
-
|
12V-26AH
|
|
Dimension (L×W×H)
|
mm
|
930×620×640
|
|
Net Dry Mass
|
Kg
|
155
|
|
Noise level(7m)
|
dB
|
75
|
