Product Details:
|
| Rated Input Voltage: | 220V±15% | Rated Duty Cycle @40°C: | 80% |
|---|---|---|---|
| Max. Load Power Capacity: | 40kva | Rated Output Voltage: | 85 V |
| Rated Output Current: | 500 | Welding Current/Voltage Range: | 30-400A |
| Condition: | New | Pulse Frequency: | 885 |
| Motor Type: | DC MOTOR | Dimensions: | 1500*700*700MM |
| Use: | PIPELINE WELDING | Weight (KG): | 700 KG |
| Warranty: | 1 Year | Key Selling Points: | WELDER + GENERATOR |
| Applicable Industries: | Manufacturing Plant, Construction Works , Energy & Mining | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Feature: | Multifunction |
| Welding Machine Type: | ENGINE DRIVEN WELDER | Function: | Welder + Generator |
| Port: | TIANJIN |
Generator | |||
DC Welder (CC MODE) | |||
Rated Output | KW | 14.4 | |
Rated Current | A | 400 | |
Rated Voltage | V | 36 | |
Current Range (Single) | A | 60-400 | |
Current Range（Dual） | A | 30-220 | |
Open-circuit Voltage | V | 80 | |
Duty Cycle | % | 90 | |
Rated speed | rpm | 1500 | |
Type | - | Rectified DC output type | |
Applicable Electrode | mm | 2.0-6.0 | |
DC Welder (CV MODE) | |||
Voltage Range | V | ||
Rated Current | A | ||
Aux. Power | |||
Rated Output | KVA | 20 | |
Rated Voltage | ACV | 120/220/380/415 | |
Phase | - | 3-phase/4 wires | |
Power Factor | % | 80 | |
Frequency | Hz | 50 | |
Rated Speed | rpm/min | 1500 | |
Excitation | - | Brushless | |
Driven | - | Direct Coupling | |
Engine | |||
Model | - | ISUZU ENGINE | |
Type | - | 4-cycle, water-cooled diesel engine | |
Cylinder arrangement | - | 4-L | |
Total displacement | cc | 2270 | |
Rated Output | KW | 19.0 | |
Speed | rpm | 1500 | |
Cooling System | - | Water-cooled by radiator type | |
Driven | - | Direct Coupling | |
Fuel | Light diesel oil | ||
Start System | - | Electric motor（12V） | |
Fuel Tank Capacity | L | 50 | |
Oil Capacity | L | 7.4 | |
Battery Capacity | - | 12V- 95D31 | |
Dimension （L×W×H） | mm | 1650×650×905 | |
Net Dry Mass | Kg | 750 | |
Operating Mass | Kg | 800 | |
